Industrial Valves

Lubricated plug valve cross-sectionA cross-sectional diagram reveals the key components that enable the valve to operate. The main features include:

• Body: The main housing of the valve, which connects to the pipeline.
• Plug: A cylindrical or conical rotating component with a hole bored through it. A quarter-turn of the plug aligns or misaligns the hole with the pipeline to control flow.
• Lubricant Injection Fitting: Located at the top of the plug, this is where the sealant is injected under pressure.
• Lubricant Channels: The sealant is delivered from the injection fitting, down the plug's central cavity, and out through radial holes to grooves on the plug's surface.
• Lubricant Grooves: These grooves on the plug's surface help distribute the sealant between the plug and the body, reducing friction and ensuring a bubble-tight seal.
• Check Valve: Positioned below the injection fitting, this prevents the sealant from flowing back up once injected.
• Lubricant Chamber: A chamber at the bottom of the plug holds the sealant.

An actuator butterfly valve is a valve with an attached automated mechanism, called an actuator, that opens, closes, or modulates the valve. This eliminates the need for manual operation via a handwheel or lever. The two most common actuator types are electric and pneumatic.

Additional Information:

• Production Capacity: 100
• Delivery Time: 1 WEEK
• Packaging Details: WOODEN

We "Swami Valves And Engineers" are a Manufacturer of Ball Valve, Pressure Reducing Valve, Check Valve, Gate Valve, Relief Valve, Cast Iron Strainer, Pressure Reducing Station, MS Flame Arrestor, MS Globe Valve, etc.

Additional Information:

• Production Capacity: 150
• Delivery Time: 1 TO 4 WEEKS
• Packaging Details: WOODEN

Gear-operated butterfly valves are designed to provide efficient flow control in pipelines, utilizing a gear mechanism to enhance torque and facilitate easier operation, especially in larger valves.

Additional Information:

• Production Capacity: 200
• Delivery Time: 1 TO 4 WEEK
• Packaging Details: WOODEN

Common features

• On/off control: The actuator rotates the ball valve 90 degrees to fully open or fully close the flow of the medium.
• Modulating control: Certain electrical actuators can be configured for modulating duty, which allows for precise control of the flow rate.
• Manual override: Many actuated valves include a manual override, such as a wrench or wheel, for operation during power failure or for maintenance.
• Enclosure and protection: Actuators are often built with robust housings to protect against weather and dust, with ratings such as IP67.

A pneumatic ball valve is an automated valve that uses compressed air to rotate a hollow, spherical ball to control the flow of media like liquid, gas, or steam. It is often used in automated industrial settings where remote or quick control is needed, and is a safe choice for hazardous environments where electrical actuators could cause a spark.

Additional Information:

• Production Capacity: 100
• Delivery Time: 2 WEEKS
• Packaging Details: WOODEN
